Temperature Auxiliary Features
- T-type thermocouple sensor
- Quick response and sampling for temperature change
- Accurate temperature measurement based on cold junction compensation technology
- Temperature test: -50℃~200℃
- Up to 32 independent channels in each module
- 24-bit high-precision ADC chip
- Multiple Aux channels can be mapped to a primary testing channel. A single Aux channel
- can be mapped to multiple primary channels
Voltage Auxiliary Features
- Up to 32 fully independent channels in each unit
- Voltage resolution of 0.1mV
- Over-voltage protection up to 1000V
- 24-bit high-precision ADC chip
- Multiple Aux channels can be mapped to a primary testing channel. A single Aux channel
- can be mapped to multiple primary channels.
