The hot roller press machine is designed for the electric calendaring of battery electrodes in a laboratory. It is suitable for thinning the electrodes and increasing the tap density of electrode sheets, thus increasing the energy density of the battery cells. It is also used to roll small amounts of precious metal materials, such as gold and silver, and non-ferrous materials, such as copper and aluminum, with the rolling temperature controlled. The rolling thickness is adjustable, and the operation is simple.
SPECIFICATIONS:
| Model | LT-JS100 | LT-JS200 |
|---|---|---|
| Roller dimension | 96mm (Dia.) * 100mm (W) | 96mm (Dia.) * 200mm (W) |
| Roller hardness | HRC62 | HRC62 |
| Roller finish | Ra0.4 or above | Ra0.4 or above |
| Roller cylindricity | ≤±2um | ≤±2um |
| Rolling thickness | 0~2mm, adjustable | 0~2mm, adjustable |
| Heatable width | 100mm | 200mm |
| Adjustable gap | 0~2mm | 0~2mm |
| Roller placement | Vertically placed | Vertically placed |
| Rolling temperature | Room temperature ~ 130℃ adjustable with digital display | Room temperature ~ 130℃ adjustable with digital display |
| Temperature control accuracy | ±0.5℃ | ±0.5℃ |
| Voltage | AC220V/50Hz, or AC110V/60Hz | AC220V/50Hz, or AC110V/60Hz |
| Power | 1.5KW | 1.5KW |
| Feeding speed | 0~40mm/s | 0~40mm/s |
| Dimension | 500mm*220mm*320mm (L*W*H) | 505mm*220mm*320mm (L*W*H) |
| Net Weight | 90KG | 100KG |
