This Automatic Electrode Slitting Machine ensures precise sealing and shaping of the pouch cell edges, which is critical for preventing electrolyte leakage, maintaining structural integrity, and ensuring long-term performance. It can be used for cutting independently. This machine is equipped with an automatic cutting function. The loading shaft is a pneumatic shaft, which is convenient for loading and unloading.
Features
- It can set cutting length, quantity, and speed arbitrarily, and can perform cutting independently.
- Automatic tension adjustment.
- Continuous cutting is available in two modes: fixed length and cursor tracking, suitable for multi-segment cutting. Front and rear compensation at the incision can be set.
- The machine is controlled by a PLC touchscreen control panel, which is convenient and easy to operate.
- Exquisite appearance: the sheet metal features a three-dimensional geometric design, ensuring simple operation, safety, reliability, and a compact size.
Specifications
| Product Name | Automatic Electrode Slitting Machine |
| Tension Control | Min: 10N |
| Cutting Speed | 1 – 5 m/min |
| Acceptable Electrode Roll Size | Maximum O.D. of 250 mm |
| Burrs Condition | ±0.005mm |
| Voltage | AC220V/50Hz, or AC110V/60Hz |
| Rated Power | 1.2KW |
| Compressed Air Requirement | 0.5 Mpa-0.8 Mpa |
| Acceptable Electrode Width | 0 – 300 mm |
| Product Dimension | 1100*800*700mm(L*W*H) |
| Net Weight | About 240 kg. |
