Lab Roller Press Machine is an ideal rolling press tool for modifying the electrode’s thickness and increasing its active material density in Li-Ion batteries. This machine adopts a gear transmission to achieve roll pressing. It is especially suitable for lithium battery electrodes made of clean energy materials. The thickness of the rolling is adjustable.
SPECIFICATIONS:
| Model | LT-SG100L | LT-SG200L |
|---|---|---|
| Roller Size | 96mm (Dia.) * 100mm (W) | 96mm (Dia.) * 200mm (W) |
| Roller Cylindricity | ≤±2um | ≤±2um |
| Roller Hardness | above HRC62 | above HRC62 |
| Roller Smoothness | 0.4 or above | 0.4 or above |
| Rolling Thickness | 0~2mm, adjustable | 0~2mm, adjustable |
| Roller Placement | Vertically placed | Vertically placed |
| Operation Mode | Manual | Manual |
| Feeding Speed | 0~40mm/s (Depends on manual operating speed) | 0~40mm/s (Depends on manual operating speed) |
| Product Dimensions | 409mm*350mm*489mm (L*W*H) | 515mm*350mm*489mm (L*W*H) |
| Net Weight | 45KG | 50KG |
